PowertrainCummins QSF 2.8 64 hp Omsi Axles with SAHR vrakes and 100% differential lock 460/70R 24 Michelin Bib Load hard surface tires centered on 82″ 210″ Wheelbase 8″ Axle Jacks on Mast end of machine Steel construction on Main Machine 12 Pallet Chain Transfer Deck Powered Fold up PlatformsPull out tubes to support Platforms ControlsCentered Drivers Station with SS Dash Remote control box tether with dead-man switch. Wing Speed Control on the right wing Chain Transfer switches on the left and right rear of the machine along with rear steer control and E-Stop Self-centering rear axle Wing Hydraulic Lift and Rotate Stainless Wing ConstructionWith open design for boxes to push easily onto a folding powered conveyor 16″ wide conveyor, hydraulicly powered Folding shade Canopy on both sides and wind flap on the conveyor side of the wing that makes a tunnel around the conveyor SS roller with plastic roller ends and hollow shaft Full length box slide Hydraulically driven Generator for 120VAC single phase power Mast WaterHydraulic driven water pump 170 gallon Stainless steel tank Spray nozzles on the wings for cleaning product 60 Gallon Stainless Steel Diesel Tank
Stainless Steel Construction 12.4 x 24 tires on 82 inch centers OMSI drive/steer planetary axles with 100% differential lock, and SAHR brakes Machine top speed around 5 mph Axle jacks for loading onto the trailer Four Wheel steering with automatic centering rear axle QSF3.8 Cummins Tier 4 Final Engine, 130 hp Standard Valley Fab Header and Float systemSupply water on the pick up belt for reduced friction and cooling Standard Mol pickup belt Squirrel cage mouse or forward blower mounted to the front of the conveyor (Optional) Standard air jump Standard 3/4″ nose bar Removable belt side supports Incline conveyor RMV with 4 inch flights One Sort conveyor with Dual Agitators, Dual Stainless Steel Augers 100 gal Water tank with hydraulic water pump Forward facing Mouse Blower (Optional) Standard VFI float header with float system 20″ wide cross conveyor with lift linkage to go from bulk to totes mode Side load elevator, 24″ wide white RMV crescent top belt Elevator rotates out to reach both the close and far bins on the trailer 180 folding tote sweep with either UHMW or Round bar bottom Powered empty tote in-feed conveyor Machine under 120″ width
Positions for 12 pallets, 10 on the main chains and 2 on the slide outs 2 saddle tanks each with approximately 200 gallon capacity each (400 total) There will be a 150+ gpm Pacer hydraulically driven water pump for filling harvester tanks A set of squeeze racks with folding gate to allow room for pallets on the slide outs Cummins QSF3.8 Tier 4 Final, 130 hp OMSI Axles Pressure washer There will be a folding headboard
Positions for 10 pallets, 6 chains Machine has steel construction with stainless steel squeeze channels, engine cover, driver’s station, diesel and hydraulic tanks Folding headboard, approximately 88″ tall without a flip -over estension Deck jacks on rear of the vehicle A set of squeeze racks, the full length of the chains Steel Diamond floor plate under chains Horn locks on transfer sockets for coupling to the mating machine Engine Cummins 3.8 QSF Tier 4 Final OMSI axle for drive train A second control station with all the transfer functions is located in the left rear (drivers’s side) which can be activated from the cab only when in low gear
Machine Features:
Stainless Steel Chassis construction with aluminum wings Tricycle 3-wheel design: 1 front steering wheel and 2 rear diving wheels Two speed gearbox Parking break on front wheel A 1500 lb. pallet forklift assembly for on board palatalization Hydraulic power unit to power the forklift Four solar panels and charge controller Four 6VDC deep cycle batteries Bi-folding aluminum wings Rear wheel supports can be moved to 48″, 52″, 64″ and 68″ beds.
Totes and bulk machine Stainless steel construction except the undercarriage 120″ folded width Tote seep made of bars or UHMW base 12″ x 264 Rubber tracks, centered on 80″ Cummins QSF 3.8 tier 4 Final engine, 130 hp Hydraulic oil cooler with electric cooling fan Standard VF header with;Supply water on the pick up belt for reduced friction and cooling Standard Mol pickup belt Squirrel cage mouse or forward blower mounted to the front of the conveyor (Optional) Standard air jump Standard 3/4″ nose bar Removable belt side supports Features 2 sort conveyorsBoth with 1″ x 1″ stainless steel flat wire beltOptional 1/2″ x 1″ stainless steel flat wire belt Both have stainless steel cull auger The 2nd sort conveyor featuresSpray bar for washing product Grab bar near rear for personal to hold onto Plastic triangular agitators with adjustable agitation speed 16″ wide, white smooth RMV, Cross conveyor that moves up and down to transition between totes and bulk mode Stainless see wash down rated foot switch for Turning cross conveyor on when in totes mode 16″ Tote Exit conveyor, Rough top belting, constantly powered on Tray on exit conveyor for holding the discharging tote 18″ wide Tech-Roll driven Elevator conveyor with 4″ flights on 12″ centers Electric flipper to push product from inside to outside bin Approximately 80 gal water tank
